Human Angiogenesis Array G1000

Hersteller Raybiotech
Kategorie
Typ Array
Specific against Human
Menge 8 Sample Kit
Host Hamster - Armenian
ArtNr AAH-ANG-G1000-8
Targets ANG ;; IL2 ;; IL4 ;; IL6 ;; KDR ;; LEP ;; PGF ;; TEK ;;ANGPT1;;ANGPT2;;CCL2;;CCL5;;CXCL8;;FLT4;;FOXD3;;IL10;;IL1A;;IL1B;;MMP9;;PECAM1;;TGFB1;;THPO;;TIMP1;;VEGFA;;VEGFD
eClass 6.1 32161000
eClass 9.0 32161000
Lieferbar
Compatible Sample Types
Cell Culture Supernatants, Plasma, Serum, Tissue Lysates, Cell Lysates
Design Principle
Sandwich-based
Detection Method
Fluorescence Laser Scanner
Features
  • High sensitivity and specificity
  • Low sample volume (10-100 ul per array)
  • Large dynamic range of detection
  • Compatible with most sample types
  • Test 4 or 8 samples on each slide
  • Suitable for high-throughput assays
Kit Components
  • Human Angiogenesis Antibody Array G1000 Slide(s)
  • Blocking Buffer
  • Wash Buffer 1
  • Wash Buffer 2
  • Biotinylated Detection Antibody Cocktail
  • Streptavidin-Conjugated Fluor
  • Lysis Buffer
  • Adhesive Plastic Strips
  • 30 ml Centrifuge Tube
  • Manual
Number of Targets Detected
43
Other Materials Required
  • Small plastic boxes or containers
  • Pipettors, pipette tips and other common lab consumables
  • Orbital shaker or oscillating rocker
  • Aluminum foil
  • Gene microarray scanner or similar laser fluorescence scanner
Protocol Outline
  1. Dry the glass slide
  2. Block array surface
  3. Incubate with Sample
  4. Incubate with Biotinylated Detection Antibody Cocktail
  5. Incubate with Streptavidin-Conjugated Fluor
  6. Disassemble the glass slide
  7. Scan with a gene microarray laser scanner
  8. Perform densitometry and analysis
Result Output
Semi-Quantitative
Short description
RayBio G-Series Human Angiogenesis Antibody Array 1000 Kit. A combination of Human Angiogenesis Antibody Array G1 & G2. Detects 43 Human Angiogenic Factors. Suitable for all liquid sample types.
Solid Support
Glass Slide
Storage
For best results, store the entire kit frozen at -20C upon arrival. Stored frozen, the kit will be stable for at least 6 months which is the duration of the product warranty period. Once thawed, store array slide(s) and 1X Blocking Buffer at -20C and all other reagents undiluted at 4C for no more than 3 months.
Targets Detected
Angiogenin, Angiopoietin-1, Angiopoietin-2, Angiostatin, bFGF, CCL1, CCL13, CCL2, CCL5, CCL7, CD31, CXCL11, CXCL5, CXCL8, EGF, ENA-78, Endostatin, G-CSF, GM-CSF, GRO, I-309, I-TAC, IFN-gamma, IGF-1, IL-1 alpha, IL-1 beta, IL-1 F1, IL-1 F2, IL-10, IL-2, IL-4, IL-6, IL-8, Leptin, MARC, MCP-1, MCP-3, MCP-4, MMP-1, MMP-9, PDGF-BB, PECAM-1, PlGF, RANTES, TCA-3, TGF beta 1, Thrombopoietin, Tie-2, TIMP-1, TIMP-2, TNF alpha, TPO, uPAR, VEGF-A, VEGF-D, VEGFR2, VEGFR3

Hinweis: Die dargestellten Informationen und Dokumente (Bedienungsanleitung, Produktdatenblatt, Sicherheitsdatenblatt und Analysezertifikat) entsprechen unserem letzten Update und sollten lediglich der Orientierung dienen. Wir übernehmen keine Garantie für die Aktualität. Für spezifische Anforderungen bitten wir Sie, uns eine Anfrage zu stellen.

Alle Produkte sind nur für Forschungszwecke bestimmt. Nicht für den menschlichen, tierärztlichen oder therapeutischen Gebrauch.
