Comparison

TTN Antibody (monoclonal) (M09)

Item no. ABC-AT4394a
Manufacturer Abcepta
Amount 100 ug
Category
Type Antibody Primary
Format Clear, colorless solution in phosphate buffered saline, pH 7.2 .
Applications WB, IF, IHC, ELISA
Clone 6H5
Specific against other
Host Mouse
ECLASS 10.1 32160702
ECLASS 11.0 32160702
UNSPSC 12352203
Similar products Titin, TTN, Connectin, Rhabdomyosarcoma antigen MU-RMS-4014
Available
Primary Accession
Q8WZ42
Antigen Type
Recombinant Protein
Application
WB, IHC, IF, E
Bio Background
This gene encodes a large abundant protein of striated muscle. The product of this gene is divided into two regions, a N-terminal I-band and a C-terminal A-band. The I-band, which is the elastic part of the molecule, contains two regions of tandem immunoglobulin domains on either side of a PEVK region that is rich in proline, glutamate, valine and lysine. The A-band, which is thought to act as a protein-ruler, contains a mixture of immunoglobulin and fibronectin repeats, and possesses kinase activity. A N-terminal Z-disc region and a C-terminal M-line region bind to the Z-line and M-line of the sarcomere respectively so that a single titin molecule spans half the length of a sarcomere. Titin also contains binding sites for muscle associated proteins so it serves as an adhesion template for the assembly of contractile machinery in muscle cells. It has also been identified as a structural protein for chromosomes. Considerable variability exists in the I-band, the M-line and the Z-disc regions of titin. Variability in the I-band region contributes to the differences in elasticity of different titin isoforms and, therefore, to the differences in elasticity of different muscle types. Of the many titin variants identified, five for which complete transcript information is available are described. Mutations in this gene are associated with familial hypertrophic cardiomyopathy 9 and autoantibodies to titin are produced in patients with the autoimmune disease scleroderma.
Bio References
Variation at the NFATC2 Locus Increases the Risk of Thiazolinedinedione-Induced Edema in the Diabetes REduction Assessment with ramipril and rosiglitazone Medication (DREAM) Study. Bailey SD, et al. Diabetes Care, 2010 Jul 13. PMID 20628086.The structure of the FnIII Tandem A77-A78 points to a periodically conserved architecture in the myosin-binding region of titin. Bucher RM, et al. J Mol Biol, 2010 Sep 3. PMID 20542041.Cardiac titin: a multifunctional giant. LeWinter MM, et al. Circulation, 2010 May 18. PMID 20479164.Dynamic strength of titin's Z-disk end. Koll?r V, et al. J Biomed Biotechnol, 2010. PMID 20414364.Titin-isoform dependence of titin-actin interaction and its regulation by S100A1/Ca2+ in skinned myocardium. Fukushima H, et al. J Biomed Biotechnol, 2010. PMID 20414336.
Clonality
Monoclonal
Gene ID
7273
Gene Name
TTN
Subtitle
Mouse monoclonal antibody raised against a partial recombinant TTN.
Reactivity
H
Legend image 1
Immunofluorescence of monoclonal antibody to TTN on HeLa cell . [antibody concentration 10 ug/ml]
Type image 1
IF
Legend image 2
Antibody Reactive Against Recombinant Protein.Western Blot detection against Immunogen (37.84 KDa) .
Type image 2
WB
Dilution image 2
1:500~1000
Legend image 3
Western Blot analysis of TTN expression in transfected 293T cell line by TTN monoclonal antibody (M09), clone 6H5.

Lane 1: TTN transfected lysate(32.8 KDa).
Lane 2: Non-transfected lysate.
Type image 3
WB
Dilution image 3
1:500~1000
Legend image 4
Immunoperoxidase of monoclonal antibody to TTN on formalin-fixed paraffin-embedded human heart. [antibody concentration 3 ug/ml]
Type image 4
IHC
Legend image 5
Detection limit for recombinant GST tagged TTN is approximately 0.03ng/ml as a capture antibody.
Type image 5
E
Other Accession
BC058824
Isotype
IgG2a Kappa
Antigen Source
Human: ~~ Positive
Target/Specificity
TTN (AAH58824, 1 a.a. ~ 110 a.a) partial recombinant protein with GST tag. MW of the GST tag alone is 26 KDa.
NCBI Accession
NP_001243779.1; NP_001254479.1; NP_003310.4; NP_596869.4; NP_596870.2; NP_597676.3; NP_597681.3
Clone: 6H5
Org Accession
AAH58824
Gene Description
titin
Gene Summary
This gene encodes a large abundant protein of striated muscle. The product of this gene is divided into two regions, a N-terminal I-band and a C-terminal A-band. The I-band, which is the elastic part of the molecule, contains two regions of tandem immunoglobulin domains on either side of a PEVK region that is rich in proline, glutamate, valine and lysine. The A-band, which is thought to act as a protein-ruler, contains a mixture of immunoglobulin and fibronectin repeats, and possesses kinase activity. A N-terminal Z-disc region and a C-terminal M-line region bind to the Z-line and M-line of the sarcomere respectively so that a single titin molecule spans half the length of a sarcomere. Titin also contains binding sites for muscle associated proteins so it serves as an adhesion template for the assembly of contractile machinery in muscle cells. It has also been identified as a structural protein for chromosomes. Considerable variability exists in the I-band, the M-line and the Z-disc regions of titin. Variability in the I-band region contributes to the differences in elasticity of different titin isoforms and, therefore, to the differences in elasticity of different muscle types. Of the many titin variants identified, five for which complete transcript information is available are described. Mutations in this gene are associated with familial hypertrophic cardiomyopathy 9 and autoantibodies to titin are produced in patients with the autoimmune disease scleroderma. [provided by RefSeq
